Lenovo ES-511 serial server RS-232/422/485
£66.12
Lenovo ES-511, 10/100/1000Base-T(X), 5 - 30 V, 60 mA, ICMP, IP, TCP, UDP, DHCP, BOOTP, Telnet, HTTP, RFC2217, 108 g, 96.3 x 101 x 25 mm
2 in stock
SKU: 4Z10A39514
Lenovo ES-511. Cabling technology: 10/100/1000Base-T(X). Input voltage: 5 - 30 V, Power consumption: 60 mA. Supported network protocols: ICMP, IP, TCP, UDP, DHCP, BOOTP, Telnet, HTTP, RFC2217. Weight: 108 g, Dimensions (WxDxH): 96.3 x 101 x 25 mm, Package width: 22.6 mm
| Weight | 0.31kg |
|---|---|
| Specifications | Technical details Serial ports quantity: 1 Serial interface type: RS-232/422/485 Ethernet LAN data rates: 10,100 Mbit/s Flow control support: Yes Baud rate: 1000 Kbit/s Certification: RoHS, WEEE, FCC, UL, METL, TAA, AEO Ports & interfaces Ethernet LAN (RJ-45) ports: 1 Cabling technology: 10/100/1000Base-T(X) Power Input voltage: 5 - 30 V Power consumption: 60 mA Protocols Supported network protocols: ICMP, IP, TCP, UDP, DHCP, BOOTP, Telnet, HTTP, RFC2217 Indication LED indicators: Yes Weight & dimensions Weight: 108 g Dimensions (WxDxH): 96.3 x 101 x 25 mm Package width: 22.6 mm Package length: 11.4 cm Package height: 99 mm Operational conditions Operating temperature (T-T): -30 - 80 °C Storage temperature (T-T): -40 - 85 °C Operating relative humidity (H-H): 5 - 95% |
